1. Basic Information
Item | Specification |
Model | DFZ5250GFWBX1V |
Product Name | 15m³ Strong Acid Transport Tanker Truck |
Brand | Dongfeng |
Transport Medium | Concentrated sulfuric acid (98%), hydrochloric acid (31%), nitric acid (68%) |
Gross Vehicle Weight (GVW) | 25,000 kg |
Curb Weight | 11,800 kg |
Rated Loading Capacity | 12,905 kg |
Overall Dimensions (L×W×H) | 9,600 × 2,550 × 3,950 mm |
Wheelbase | 5,600 mm |
Axle Configuration | 4×2 (2 axles) |
2. Chassis Configuration
Engine Model: Dongfeng Cummins ISB6.7-C290 50
Engine Power: 213 kW (290 HP) @ 2,500 rpm
Engine Displacement: 6,700 cc
Emission Standard: Euro V
Transmission: 9-speed manual transmission (9JS119TA-B)
Clutch: Dry single-plate clutch with hydraulic control
Front Axle: 5.5T drum brake axle
Rear Axle: 10T single reduction drum brake axle (speed ratio: 4.875)
Tires: 11.00R20 16PR radial tires (6 tires + 1 spare tire)
Suspension: Leaf spring suspension (front: 9 leaves; rear: 11 leaves)
Fuel Tank Capacity: 300 L (carbon steel)
Battery: 2×12V 150Ah maintenance-free batteries
Steering System: Power steering (hydraulic assisted)
Braking System: Air brake with ABS + EBD, exhaust brake
3. Tank Body Specifications
Tank Material: High-quality PP (polypropylene) with corrosion-resistant coating
Tank Volume: Effective volume 15 m³ (total volume 15.8 m³)
Tank Structure: Integral one-piece molding, no welding seams (leak-proof design)
Tank Thickness: 12 mm (PP layer) + 5 mm reinforced outer layer
Tank Dimensions (L×D): 7,200 × 1,600 mm (cylindrical structure)
Manhole: 1×DN500 mm manhole cover (flange connection, acid-resistant seal)
Inlet/Outlet: 1×DN80 mm acid-resistant PP ball valve (bottom discharge)
Level Gauge: Magnetic liquid level gauge (acid-proof, range 0-15 m³)
Ventilation Device: Acid-resistant breathing valve (prevents pressure build-up)
Anti-sloshing Design: Internal anti-wave plates (3 partitions)
Tank Color: White (anti-corrosion paint, RAL 9010)
4. Safety Configuration
Corrosion Protection: Full PP lining + external anti-corrosion coating
Leakage Prevention: Double-seal flange connections, pressure test passed (0.3 MPa)
Safety Valves: Emergency pressure relief valve (set pressure: 0.15 MPa)
Fire Protection: 2×5 kg dry powder fire extinguishers (placed in dedicated bracket)
Warning Signs: Reflective "DANGER - STRONG ACID" signs (front/rear/side)
Grounding Device: Static grounding strip (with automatic connection reminder)
Emergency Kit: Acid-resistant gloves, goggles, chemical neutralizer (sodium carbonate)
Stability Enhancement: Anti-roll bars on both sides of the tank
Lighting: LED warning lights (red, 4 sets) + reflective strips
5. Operation & Control
Discharge Control: Manual operation of bottom ball valve (with extended handle)
Level Monitoring: Visible magnetic level gauge + optional digital display
Temperature Monitoring: Built-in temperature sensor (range: -10℃ ~ 80℃)
Operating Temperature Range: -20℃ ~ 60℃
Maximum Operating Pressure: 0.1 MPa (tank internal pressure)
6. Compliance & Certification
Certifications: ISO 9001, CCC (China Compulsory Certification), ADR (European Agreement Concerning the International Carriage of Dangerous Goods by Road)
Dangerous Goods Class: Class 8 (Corrosive Substances)
Manufacturing Standard: GB 18564.1-2019 (China national standard for dangerous goods transport vehicles)
Warranty Period: 1 year or 30,000 km (whichever comes first)
7. Optional Configurations
Digital remote control for discharge valve
GPS positioning + real-time monitoring system
Heating system (for low-temperature environments)
Larger diameter discharge pipeline (DN100 mm)
Custom tank color or company logo printing
Additional emergency neutralizer storage box
