The 5-cubic-meter Dongfeng Furika water tanker is mainly used for large-scale watering and dust suppression and greening irrigation in scenarios such as urban main roads, highway watering, large construction site dust suppression, and mining area haze removal. It is the main vehicle for sanitation operations.
| Technical Specifications of Dongfeng Furika Water Tank Truck | |||
| Product Name | sprinkler | Product Model | LOOK5070GSSE6 |
| Total mass(Kg) | 7360 | Tank volume(m3) | 4.03 |
| Rated load capacity(Kg) | 3905 | External dimensions(mm) | 5990×2050×2430 |
| curb weight(Kg) | 3325 | Number of passengers allowed in the driver's cab (persons) | 3 |
| Approach angle/Departure angle(°) | 27.7/14.5 | Front/Rear Suspension(mm) | 1055/1627 |
| Axle load(Kg) | 2640/4720 | Top speed(Km/h) | 110100 |
| 1. This vehicle is mainly used for landscaping and greening, with a dedicated spraying assembly. 2. Optional features include: cab (selectable from chassis), taillight bracket style, installation positions for the fuel tank, filter, urea tank, battery, and air tank (selectable from chassis), exterior style, high-level shower head, arrow lights, toolbox, pneumatic ball valve, front-mounted duckbill valve, and rear platform piping style. ABS model/manufacturer: ABS/ASR-12V-4S/4M/Xiangyang Dongfeng Longcheng Machinery Co., Ltd. Rear arrow lights are optional (only used during operation), high-pressure water cannon style, pneumatic valve, and side spray style. | |||
| Chassis technical parameters | |||
| Chassis Model | EQ1075SJ3CDF | Chassis Name | Cargo truck chassis |
| Trademark Name | Dongfeng brand | manufacturing enterprises | Dongfeng Motor Co., Ltd. |
| Number of axes | 2 | Number of tires | 6 |
| wheelbase (mm) | 3308 | Tire specifications | 7.00R16 |
| Number of leaf springs | 8/10+7 | Front wheel track(mm) | 1609 |
| Fuel types | diesel fuel | Rear wheel track(mm) | 1564 |
| Emission standards | GB17691-2018 Country VI | ||
| Engine Model | Engine manufacturers | Displacement(ml) | power(Kw) |
| CY4BK461 | Dongfeng Chaoyang Chaichai Power Co., Ltd. | 3707 | 95 |
The Dongfeng Furika water sprinkler truck is a special-purpose vehicle integrating water sprinkling and dust suppression functions. It has a tank capacity of 5 cubic meters and is widely used in road dust control, landscaping, disinfection, and other fields. The following is an introduction to the Dongfeng Furika water sprinkler truck:
Chassis Configuration: Diesel engine, Wanliyang gearbox, 3308mm wheelbase, 7.00R16 steel radial tires, air brakes, power steering, equipped with a Dongfeng Huashen 1070 single-row cab with tilting mechanism.
Upper Structure Configuration: The tank is made of 4mm carbon steel plate with internal anti-surge baffles. The vehicle comes with a dedicated water pump with a maximum vertical suction lift of 6 meters and a sprinkling width of 14 meters. A high-pressure water cannon for landscaping is installed on the rear working platform; it can rotate 360 degrees and the mist spray is adjustable.
