The LK5180THY Airport Cargo Truck is professionally modified based on a high-quality automobile chassis, specifically designed for cargo transportation scenarios in airports. Its core advantages are as follows:
Strong Load-Bearing Capacity: Adopting a high-strength frame and an optimized load-bearing structure, it can meet the transportation needs of various types of cargo in airports (including standard air cargo containers). The rated load is suitable for mainstream freight scenarios.
High Operational Convenience: Equipped with flexible loading and unloading auxiliary devices, combined with a reasonable cargo compartment layout, it reduces cargo transfer links, improves loading and unloading efficiency, and lowers the intensity of manual operations.
Reliable Safety Performance: Equipped with multiple safety protection systems, including anti-lock braking system, stability control, and cargo compartment limit device, etc., to ensure the safety of the vehicle during driving and parking in the complex operating environment of the airport.
Wide Adaptability to Scenarios: It can be matched with the cargo loading and unloading systems of mainstream civil aviation aircraft models such as Airbus A320, A330, Boeing B737, B777, etc. At the same time, it is compatible with the operating requirements of different areas in the airport (cargo area, tarmac, etc.).
Outstanding Durability: Key components are selected from well-known brand products, and the cargo compartment is made of corrosion-resistant and wear-resistant materials, which can adapt to the high-frequency and long-time operation intensity of the airport and extend the service life of the vehicle.
Item | Configuration |
Engine | |
- Manufacturer | FAW |
- Model | CA6DH1-26E61 |
- Rated Power (kW) | 192 |
- Emission Standard | Euro 5 |
Transmission | |
- Manufacturer | Shaanxi Fast Gear Co., Ltd. |
- Model | 8JS95TE-C |
- Number of Gears | 8 gears (8 forward, 2 reverse) |
Chassis | |
- Manufacturer | FAW Automobile Co., Ltd. |
- Model | CA1180P62K1L4E6 |
- Drive Form | 4×2 |
- Wheelbase (mm) | 5100 |
Cargo Compartment Parameters | |
- Type of Cargo Compartment | Closed cargo compartment (with side-opening/rear-opening doors) |
- Internal Dimensions of Cargo Compartment (Length × Width × Height) (mm) | 7200×2450×2500 |
- Rated Load of Cargo Compartment (kg) | 8500 |
- Material of Cargo Compartment | Aluminum alloy composite panel (lightweight) |
Vehicle Parameters | |
- Curb Weight (kg) | 8200 |
- Maximum Total Mass (kg) | 18000 |
- Overall Dimensions (Length × Width × Height) (mm) | 9800×2550×3800 |
- Maximum Speed (km/h) | 90 |
Safety Configuration | |
- Braking System | Front disc and rear drum + ABS + EBD |
- Auxiliary Safety Devices | Reverse image + reverse radar |
- Cargo Compartment Safety Facilities | Anti-theft device for cargo compartment door lock |
Efficient Freight Design: The size of the cargo compartment is suitable for standard air cargo containers. Some configurations are equipped with hydraulic tailgates, which greatly improve loading and unloading efficiency, reduce cargo transfer time, and meet the "fast turnover" demand of airport freight.
Stable Power Performance: The main configuration adopts FAW chassis, which has sufficient power and economical fuel consumption. It balances high-load operation and low operating cost, and meets environmental protection requirements.
Flexible Scenario Adaptation: Different versions of wheelbase, cargo compartment material and safety configuration can be matched with different scenarios such as short-distance transportation in the airport and cross-regional freight, and are compatible with the freight needs of various aircraft models.
Comprehensive Safety Protection: From driving safety (ABS, ESC) to cargo safety (anti-theft door locks, fixing devices), a multi-dimensional protection system is built to adapt to the high-safety standard operating environment of the airport.
