Shacman 25-ton tipper truck features a Weichai diesel engine, 10-speed gearbox, and Hyva hydraulic lift. Optional RHD configuration makes it ideal for heavy-duty construction, mining, and material transport tasks.
| GVW | Driving Type 6x4 | |
Model | Luke | |
Cab | SHACMAN H3000 four-point hydraulic suspension cab,electric automatic constant temperature air conditioner,power window,ordinary air filter,central lock,hydraulic major seat,tilt,metal bumper | |
Engine(Hp) | 340 | |
Power(Kw) | 250 | |
Wheelbase | 3775+1400,3800+1350 | |
Front/Rear Suspension | 1525/1825 | |
Steering | Power steering | |
Approach/departure angle | 28/16 | |
Wheels & tire | 12.00R20 | |
Tire number | 10+1 | |
Tank Dimensions(mm) | 5400,5600×2300×1200,1500 | |
Cubage (m3) | 18/20 | |
Steel thickness | Side 6 ,Bottom 8 | |
RHD or LHD | optional | |
Overall Dimensions(mm) | 8200,8500×2500×3450 | |
Curb weight (Kg) | 12400 | |
Engine | Model | WP10.340E22 |
Horsepower | 340 | |
Maximum output Kw | 250 | |
Maximum torque N.m | 1350 | |
Type | 6cylinders, in-line,4-stroke,turbo inter-cooling, diesel engine | |
Displacement | 9.726L | |
Weichai brand, Euro 2 | ||
Driving passenger | 2,3 | |
Transmission | FAST 10 forwards,2 reverse,manual | |
Front Axle | 9.5T | |
Rear Axle | 16T x2 | |
Brake System | air brake exhaust brake | |
Color and LOGO | customized | |
Electric system | 24V | |
Standard configuration | The dump is unloaded from behind, hydraulic cover is optional. The side protection using cold-formed steel /Q235-A, bolt connection. The back protection using cold-formed steel /Q235-A, welding connection. Side 6mm, bottom 8mm. | |
Delivery date | Within 40 days after receipt advance | |
Packing | Nude Pack .The packing of the commodity shall be in accordance with the export standard packing of the manufacturer, be suitable for long distance transportation of ocean and inland. The Seller shall be take measures against moisture, shocks and rust according to the special needs of the commodity. | |
