Shacman 8,000 L fire truck is a reliable medium-duty vehicle featuring an 8,000 L water tank, a 65 L/s pump, and a 230 hp diesel engine with 4×2 drive. Its sturdy chassis ensures stable performance, making it ideal for urban and rural emergency firefighting.
Category | Parameter | Specification |
Basic Information | Model Name | Shacman 8000L Fire Truck |
Product Type | Medium-Duty Urban & Suburban Firefighting Vehicle | |
Compliance Standard | ISO 3833 (Firefighting Vehicle Classification), EN 1846 (Fire Pump Performance), Euro V / China VI Emission Standard | |
Powertrain | Engine Model | Weichai WP4.1NQ220E50 Turbocharged Diesel Engine |
Maximum Power | 162 kW (220 hp) @ 2,600 rpm | |
Peak Torque | 600 N·m @ 1,400-2,200 rpm | |
Fuel Type | Diesel | |
Fuel Tank Capacity | 120 L | |
Continuous Operation Range | ≥ 400 km (Under Full Water Load & Standard Driving Condition) | |
Transmission & Mobility | Drive System | 4×2 Rear-Wheel Drive (Optional 4×4 Drive for Off-Road Demand) |
Transmission Type | 6-Speed Manual Transmission (Optional 6-Speed Automatic Transmission) | |
Maximum Gradability | ≥ 35% (19.3°) | |
Minimum Ground Clearance | 240 mm | |
Turning Radius | ≤ 7.5 m (Minimum Turning Diameter) | |
Firefighting Core System | Water Tank Capacity | 8,000 L High-Density Polyethylene (HDPE) Tank (Anti-Corrosion, Leak-Proof) |
Fire Pump Type | Single-Stage Centrifugal Fire Pump (Compliant with EN 1846 Class B) | |
Pump Flow Rate | 70 L/s (4,200 L/min) @ 1.0 MPa Working Pressure | |
Maximum Pump Pressure | 1.6 MPa | |
Water Monitor (Cannon) | Hydraulic Remote-Controlled Monitor- Horizontal Range: ≥ 60 m- Rotation: 360° Continuous- Tilt Angle: -10°~+80° | |
Foam System (Optional) | 3%~6% Automatic Foam Proportioner + 1,000 L Stainless Steel Foam Tank | |
Fire Hose Configuration | 4×20 m DN65 High-Pressure Fire Hoses + 2×30 m DN50 Medium-Pressure Hoses | |
Chassis & Structure | Chassis Model | Shacman L3000 Special Firefighting Chassis |
Frame Material | High-Strength Carbon Steel (Q345B) with Epoxy Anti-Rust Coating | |
Suspension System | Front: 3-Leaf Reinforced SpringRear: 9-Leaf Heavy-Duty Spring | |
Braking System | Dual-Circuit Air Brake + ABS (Anti-Lock Braking System) + EBD (Electronic Brake-Force Distribution) | |
Tires | 11.00R20 Radial Tires (4 Pcs + 1 Spare Tire) | |
Dimension & Weight | Overall Dimensions (L×W×H) | 7,300 mm × 2,500 mm × 3,350 mm |
Wheelbase | 4,200 mm | |
Curb Weight | 8,200 kg | |
Gross Vehicle Weight (GVW) | 16,000 kg | |
Axle Load Distribution (Front/Rear) | 5,500 kg / 10,500 kg (Under Full Water Load) | |
Safety & Operation | Safety Equipment | - Roll-Over Protection Structure (ROPS, ISO 3471)- Driver/Passenger Airbags- 2×4 kg ABC Dry Powder Fire Extinguishers- Rearview Camera + 6 Parking Sensors |
Operation Convenience | - In-Cab LCD Digital Panel (Tank Level, Pump Pressure, Engine Speed Display)- Wireless Remote for Monitor (Range: ≥ 60 m)- 360° LED Emergency Light Bar + 200 W Electronic Siren | |
After-Sales & Warranty | Warranty Period | 2 Years or 60,000 km (Whichever Comes First; Covers Engine, Fire Pump, Chassis) |
Optional Accessories | - LED Work Lights (6 Pcs)- Stainless Steel Tool Cabinet- GPS Navigation & Fleet Management System- Heating & Air-Conditioning System |
