| GVW10550kg | Driving Type 4x2 | |||
Model | LK5110GSSQ | |||
Cab | Isuzu 700P single row cab, tilted, air con | |||
Engine(Hp) | 190 | |||
Power(Kw) | 141 | |||
Wheelbase | 3815 | |||
Front/Rear Suspension | 1110/2375 (mm) | |||
Steering | Power steering | |||
Approach/departure angle | 17/12 | |||
Wheels & tire | 235/75R17.5 | |||
Tire number | 6+1 | |||
Tank Dimensions(mm) | ||||
Cubage (m3) | 8 | |||
Steel thickness of tank(mm) | 4 | |||
RHD or LHD | LHD | |||
Overall Dimensions(mm) | 7300X2250X2700 | |||
Curb weight (Kg) | 4755 | |||
Engine | Model | 4HK1-TC51 | ||
Horsepower | 190 | |||
Maximum output Kw | 141 | |||
Maximum torque N.m | 510 | |||
Type | 4 cylinders, 4 valve, 4-stroke, diesel engine | |||
Displacement | 5193ml | |||
ISUZU brand, Euro 5 | ||||
Driving passenger | 3 | |||
Transmission | ISUZU MLD 6 speed forward and one reverse, manual | |||
Front Axle | 4T | |||
Rear Axle | 7T | |||
Brake System | Oil brake | |||
Color and LOGO | customized | |||
Electric system | 24V | |||
Tank material | Carbon steel | |||
Sprinkling width | 14m each side | Suction height | 7m | |
Standard configuration | carbon steel water tank, manhole, water pump, front/side/rear spray nozzle, rear working platform, water cannon, fire valve, water valve, filter gauze, water hose, climbing ladder. | |||
Delivery date | Within 40 days after receipt advance | |||
Packing | Nude Pack. The packing of the commodity shall be in accordance with the export standard packing of the manufacturer, be suitable for long distance transportation of ocean and inland. The Seller shall be take measures against moisture, shocks and rust according to the special needs of the commodity. | |||
