The Dongfeng 6×4 water sprinkler truck is mainly used for large-scale watering and dust suppression and greening irrigation in urban main roads, highways, large construction sites, mining areas and other scenarios. It is the main vehicle for achieving "large-area, high-intensity" sanitation operations.
| Dongfeng Tianlong rear dual-axle sprinkler truck specifications | |||
| Product Trademark | Casal | Announcement batch | 399 |
| Product Name | Green spray truck | Product Model | RLQ5258GPSE6 |
| Total mass(Kg) | 25000 | Tank volume(m3) | 15.75 |
| Rated load capacity(Kg) | 14320, 14255 | External dimensions(mm) | 10640×2550×3450 |
| curb weight(Kg) | 10550 | Passenger capacity (persons) | 3 |
| Approach angle/Departure angle(°) | 23/20, 23/16 | Front/Rear Suspension(mm) | 1440/2510 |
| Axle load(Kg) | 7000/18000(Two-axis assembly) | Top speed(Km/h) | 89 |
| This vehicle is equipped with a tank, water pump, and spraying system, primarily used for urban and rural landscaping and watering. The tank's external dimensions (length/major axis/minor axis) (mm) are 6500/2300/1550, with a total tank capacity of 15.75 cubic meters and an effective tank volume of 15.00 cubic meters. Optional features include a cab style, rear treatment layout, automatic ball valve style, different pipe shapes, fan style, spraying system style, rear spray, left-side spray, right-side spray, rear platform style, right-side pipe, and LED arrow indicator lights (which only activate during operation). | |||
| Chassis technical parameters | |||
| Chassis Model | DFV1253GP6DJ | Chassis Name | Cargo truck chassis |
| Trademark Name | Dongfeng brand | manufacturing enterprises | Dongfeng Commercial Vehicle Xinjiang Co., Ltd. |
| Number of axes | 3 | Number of tires | 10 |
| wheelbase (mm) | 4350+1350 | Tire specifications | 11.00-20 16PR |
| Number of leaf springs | 9/10 | Front wheel track(mm) | 1940 |
| Fuel types | diesel fuel | Rear wheel track(mm) | 1860/1860 |
| Engine Model | Engine manufacturers | Displacement(ml) | power(Kw) |
| D6.7NS6B320 | Dongfeng Cummins Engine Co., Ltd. | 6700 | 231 |
The LOOK5258GPSE6 greening sprinkler truck is a standard-compliant special-purpose vehicle manufactured by Hubei Luku Special Vehicle Co., Ltd. Its detailed specifications are as follows:
Basic Information: Brand: Casar; Chassis Model: DFV1253GP6DJ; Number of Axles: 3; Fuel Type: Diesel; Maximum Speed: 89 km/h; Seating Capacity: 3 people.
Dimensions: Overall Length: 9650-10640mm; Width: 2500-2550mm; Height: 3150-3450mm; Wheelbase: 4350+1350mm; Front/Rear Overhang: 1440/2510mm; Approach/Departure Angles: 23/20°.
Weight Parameters: Gross Vehicle Weight: 25000kg; Curb Weight: 10550kg; Rated Load: 14255kg.
Tank Parameters: With a wheelbase of 4350mm + 1350mm, the tank dimensions are 6500/2300/1550mm, the total capacity is 15.75 cubic meters, and the effective volume is 15.00 cubic meters. The transport medium is acetone aqueous solution with a density of 950 kg/m³.
Engine Selection: Engines from companies such as Dongfeng Cummins, Weichai Power, and Guangxi Yuchai can be selected, including models such as B6.2NS6B230, D6.7NS6B320, and WP7H300E62, with power ranging from 169-231kW.
