Shacman 12-ton truck with crane integrates powerful lifting and transport functions, ensuring efficient handling for heavy construction, infrastructure, and logistics operations.
Shacman 12-Ton Truck with Crane - Export-Oriented Specification Table
| Category | Item | Specifications |
| Chassis Parameters | Engine | Weichai WP6.240E50 diesel engine (Euro V, optional Euro VI); 240 hp; 6.7L displacement |
| Transmission | 8-speed manual gearbox (e.g., Fast 8JS118); with power take-off (PTO) for crane operation | |
| Drive Configuration | 10x2 drive; Front axle load: 6.5 tons; Rear dual-axle load: 11.5 tons each | |
| Wheelbase | 5,600 mm (optimized for maneuverability and load balance) | |
| Tires | 11.00R20 all-steel radial tires; 7 pieces (including 1 spare) for multi-terrain use | |
| Crane Specifications | Max Lifting Capacity | 12,000 kg (12 tons); Telescopic boom (e.g., Zoomlion ZLJ5040JQZ12V) |
| Working Range | Max working radius: 13 meters; Max lifting height: 15 meters | |
| Hydraulic System | 22 MPa high-pressure system; Oil flow: 50 L/min (for precise, efficient control) | |
| Stability System | H-type hydraulic outriggers with adjustable legs (anti-tip design) | |
| Cargo & Dimensions | Cargo Box | 6,200x2,450x800 mm (LxWxH); 8 mm thick high-strength steel floor |
| Overall Dimensions | 9,800x2,550x3,950 mm (LxWxH); Road-legal for global mainstream markets | |
| Payload & GVW | Payload capacity: 12,000 kg; Gross Vehicle Weight (GVW): 25,000 kg | |
| Safety & Compliance | Braking System | Dual-circuit air brakes + ABS + EBD; Automatic brake gap adjustment |
| Emission Standard | Euro V (Euro VI optional, compliant with EU/US/Asian environmental regulations) | |
| Cab Safety | Reinforced cab frame; Driver airbag; Seat belts with pre-tensioners | |
| Comfort & Convenience | Cab Features | 2,200 mm wide double-row cab; Air conditioning; Adjustable steering wheel; Shock-absorbing seats |
| Applications | Target Scenarios | Construction sites, heavy logistics, mining support; Optional: Sany/XCMG crane alternatives, single/crew cab |
