Vehicle Specifications - Dimensions are generally 11900×2530×3500mm, tank dimensions are 9200×2400×1650mm. Gross vehicle weight is 32 tons, curb weight is 12 tons, registered tonnage is 19.87 tons, and both the announced and actual volumes are 29.7 cubic meters.
Chassis Configuration - Powertrain: Can be equipped with a Longqing DDi75E35060 National VI engine, producing 350 horsepower, paired with a Fast 9-speed transmission.
- Chassis Structure: Employs a 5.5-ton dual front axle and a 10-ton dual rear axle, equipped with air-suspension suspension, 295/80R22.5 tubeless tires, and alloy wheels for the front four wheels.
- Cab Configuration: Options include a white flat-top single-row cab, standard features include factory-installed air conditioning, power windows, central locking, and safety features such as front disc brakes, speed limiter, ABS, vehicle networking system, electronic braking system, and tire pressure monitoring system.
Upper Structure Configuration: The tank body is typically made of high-quality aluminum alloy sheet, characterized by its lightweight and corrosion resistance.
- Functional Systems: Equipped with constant temperature refrigeration, water temperature monitoring and display, independent oxygen supply, oxygen pressure regulation and display, and water circulation filtration systems to ensure the survival environment of live fish during transportation.
- Loading and Unloading System: Generally equipped with an independent pump room; some models have a crane fish unloading device for convenient loading and unloading of live fish.
