The FAW 4×2 wrecker truck is built on a dependable FAW chassis, featuring a 4×2 drive system that provides excellent maneuverability in urban and suburban environments. It is ideal for recovering small to medium-sized broken-down or accident vehicles, offering stable towing performance and easy operation for efficient rescue work.
| GVW4450kg | Driving Type 4x2 | ||||
Model | Luke5040TQZC | ||||
Cab | FAW VH single row, tilt | ||||
Engine(Hp) | 120 | ||||
Power(Kw) | 90 | ||||
Wheelbase | 3260 | ||||
Front/Rear Suspension | 1150/1545 | ||||
Steering | Power steering | ||||
Approach/departure angle | 21/15 | ||||
Wheels & tire | 7.0R16 | ||||
Tire number | 6+1 | ||||
Loading capacity(kg) | 3000 | ||||
Plate dimension(mm) | 4200×2300 | ||||
RHD or LHD | optional | ||||
Overall Dimensions(mm) | 5995×2300×2430 | ||||
Curb weight (Kg) | 3800 | ||||
Engine | Model | CA498E3-12 | |||
Horsepower | 120 | ||||
Maximum output Kw | 90 | ||||
Maximum torque N.m | 320 | ||||
Type | 4 cylinders, in-line, 4-stroke, diesel engine | ||||
Displacement | 3.186L | ||||
Dalian Diesel brand, Euro 2 | |||||
Driving passenger | 3 | ||||
Transmission | 5 speed forward and one reverse, manual | ||||
Front Axle | 2.8T | ||||
Rear Axle | 5T | ||||
Brake System | Automatically air-cut brake | ||||
Color and LOGO | customized | ||||
Electric system | 24V | ||||
Major parameter | Winch capacity | 4000kg | Lift capacity | 2500kg | |
Platform | 4200×2300mm | Steel wire rope | 21m | ||
Standard configuration | 2 units of towing wheel, 1 unit of 4 ton winch, 1 unit of steel wire rope, 1 unit of spare tire, 1 unit of jack, 1 unit of tire sleeve, 4 units of wrecker binding, 1 unit of alarm lamp. | ||||
Optional configuration | Flexible tail plate | ||||
Delivery date | Within 40 days after receipt advance | ||||
Packing | Nude Pack .The packing of the commodity shall be in accordance with the export standard packing of the manufacturer, be suitable for long distance transportation of ocean and inland. The Seller shall be take measures against moisture, shocks and rust according to the special needs of the commodity. | ||||
