Dongfeng 30 ton closed garbage truck is ideal for large-scale waste transport, featuring a sealed, leak-proof design and high load capacity.
Serial No. | Parameter Item | Unit | Specification | Remarks |
1 | Model | - | To be determined by the bidder | - |
2 | Engine | - | Cummins Series, Yuchai Series or Weichai Series (Euro III Emission Standard) | Complies with the requirement of Euro III emission as specified |
3 | Rated Load Capacity | Ton | 12±2 | Meets the load-carrying demand of the transportation task |
4 | Vehicle Dimension (L×W×H) | mm | Approximately 8500×2600×2800 | Overall external dimension of the vehicle |
5 | Cargo Box Dimension (L×W×H) | mm | 5400×2350×1200 | Ensures sufficient cargo capacity |
6 | Cargo Box Steel Plate Thickness | mm | ≥6 | High-strength wear-resistant steel plate is adopted |
7 | Maximum Net Power | Kw | ≥200 | Guarantees the power performance of the vehicle |
8 | Drive Type | - | 6×4 | Meets the specified drive form requirement |
9 | Tire Type | - | Steel-belted radial tire (non-vacuum tire) | Domestic well-known brands such as Chaoyang, Fengshen, Triangle, Zhengxin |
10 | Air Filter Configuration | - | Desert Air Filter + Oil-bath Type Filter | Satisfies the transportation requirement in high-dust particle environment |
11 | Cargo Box Sealing Type | - | Permanent fully enclosed type (non-permanent materials such as tarpaulin are not allowed) | - |
12 | Material Inlet & Discharge Outlet Door Control | - | Hydraulic automatic opening and closing | Ensures good sealing performance for powdery materials |
13 | Distance from Vehicle Rear to Center of Nearest Material Inlet | m | ≤2 | Meets the material feeding operation requirement |
14 | Dumping Mode | - | Front-top Oil Cylinder Rear Dumping Type | Facilitates efficient unloading of materials |
15 | Safety Configuration | - | 1. Voice reversing alarm; 2. Reverse image; 3. Vehicle body alarm radar; 4. Heating system; 5. Air conditioning; 6. Tachograph with satellite positioning function; 7. Two 4kg fire extinguishers | Comprehensive safety protection |
16 | Spare Tire | - | One spare tire of the same model and brand | For emergency replacement |
17 | First Maintenance Materials | - | Complete engine oil, filter elements, etc. for the first maintenance | Provided by the supplier (Party B) |
18 | Supporting Documents & Tools | - | 1. 3 sets of assembly drawings, complete machine parts list, operation and maintenance manual, equipment certificate; 2. 1 set of vehicle operation, maintenance and repair manual, lubrication diagram, and on-board tools per vehicle | - |
19 | Quality Guarantee Period | - | 12 months after qualified commissioning or 2000 cumulative working hours, whichever comes first | During the warranty period, free replacement or repair for quality issues |
