Isuzu 2,000 L fire truck is a compact light-duty vehicle with a 2,000 L anti-corrosion water tank, powered by a 150 hp diesel engine and 4×2 drive. Equipped with a 40 L/s pump, its compact size makes it ideal for urban small-scale emergencies and narrow areas, ensuring reliable performance.
| GVW6545kg | GVW6545kg | ||
Model | Luke5071GXFSG20 | ||
Cab | Isuzu 100P double row, air con, allowable 2+3 passengers | ||
Engine(Hp) | 98 | ||
Power(Kw) | 72 | ||
Wheelbase | 3360 | ||
Front/Rear Suspension | 1015/1880 | ||
Steering | Power steering | ||
Approach/departure angle | 24/14 | ||
Wheels & tire | 7.0R16 | ||
Tire number | 6+1 | ||
Tank Dimensions(mm) | 1765×1000×1190 | ||
Cubage (m3) | 2 | ||
RHD or LHD | LHD | ||
Overall Dimensions(mm) | 6350×2000×2750 | ||
Curb weight (Kg) | 4170 | ||
Engine | Model | 4KH1CN5LS | |
Horsepower | 98 | ||
Maximum output Kw | 72 | ||
Maximum torque N.m | |||
Type | 4 cylinders, in-line, 4-stroke, diesel engine | ||
Displacement | 2.999L | ||
Isuzu brand, Euro 5 | |||
Driving passenger | 2+3 | ||
Transmission | Isuzu MSB 5 speed forward and one reverse, manual | ||
Front Axle | 2T | ||
Rear Axle | 4T | ||
Brake System | oil brake | ||
Color and LOGO | customized | ||
Electric system | 24V | ||
Fire equipment part | Fire pump | CB10/20, rated pressure 1.0MPa, flow 20L/s | |
Fire gun | PS20, flow 20L/s , jet distance ≥45m | ||
Standard configuration | national standard equipment box, full units national standard fire-fighting equipment, fire pump, fire gun, fire power take off, sliding gate, row type lights, reel, common tools, rear climbing ladder, water tank. | ||
Optional configuration | foam type, dry powder type, stainless tank, other requirements. | ||
Delivery date | Within 50 days after receipt advance | ||
Packing | Nude Pack. The packing of the commodity shall be in accordance with the export standard packing of the manufacturer, be suitable for long distance transportation of ocean and inland. The Seller shall be take measures against moisture, shocks and rust according to the special needs of the commodity. | ||
