LOOK5165GLQEQ6 is a specialized vehicle designed for road asphalt spraying operations, featuring practicality and multiple power options. It is equipped with an elliptical asphalt tank with a total capacity of 8.8 cubic meters and an effective volume of 8.38 cubic meters. The tank has a 50mm thick insulation layer between the inner and outer tanks, which can effectively preserve liquid asphalt.
Dongfeng Dorica Asphalt Distributor Truck Parameters | |||
| Product Brand | Shenbai Heavy Industry | Announcement Batch | 395 |
| Product Name | Asphalt Distributor | Product Model | LOOK5165GLQEQ6 |
| Total Mass (Kg) | 16200 | Tank Volume (m³) | 8.8 |
| Rated Load Mass (Kg) | 7620, 7555 | Overall Dimensions (mm) | 7420 × 2460 × 3180 |
| Curb Mass (Kg) | 8450 | Number of Passengers | 3 |
| Approach/Departure Angle (°) | 19/13 | Front/Rear Overhang (mm) | 1260/2210 |
| Axle Load (Kg) | 5600/10600 | Maximum Speed (Km/h) | 89, 105 |
1. This vehicle is primarily used for asphalt distribution on roads. The specialized equipment is the tank and asphalt spraying system. 2. Asphalt tank dimensions (mm): Length 3000, elliptical cross-section with major axis 2260 and minor axis 1750. There is an insulation layer with a thickness of 50mm between the inner and outer shells. Therefore, the actual internal dimensions of the tank are 2900×2160×1650. Total tank capacity: 8.8 cubic meters, effective tank volume: 8.38 cubic meters. Medium: Liquid asphalt, density 900 kg/m³. 3. Side protection material is Q235, connected by welding. The rear is replaced by the specialized equipment, with its lower edge 480mm from the ground. ABS system manufacturer/model: Jiaozuo Borrike Control Technology Co., Ltd., J ABS; Xiangyang Dongfeng Longcheng Machinery Co., Ltd., ABS/ASR-24V-4S/4M. When equipped with a speed limiting device, the maximum speed is 89 km/h. Optional configurations include the presence or absence of toolbox structures on the left and right sides, and rear valves. | |||
| Chassis Technical Parameters | |||
| Chassis Model | EQ1165LJ9CDE | Chassis Name | Truck Chassis |
| Brand Name | Dongfeng | Manufacturer | Dongfeng Automobile Co., Ltd. |
| Number of Axles | 2 | Number of Tires | 6 |
| Wheelbase (mm) | 3950 | Tire Specification | 10.00R20 18PR |
| Leaf Spring Count (Front/Rear) | 8/10+7 | Front Track (mm) | 1862 |
| Fuel Type | Diesel | Rear Track (mm) | 1806, 1865 |
| Emission Standard | GB17691-2018 China VI | ||
| Engine Model | Engine Manufacturer | Displacement (mL) | Power (Kw) |
| B6.2NS6B230 | Dongfeng Cummins Engine Co., Ltd. | 6200 | 169 |
The LOOK5165GLQEQ6 is a special-purpose vehicle designed for road asphalt spraying operations, emphasizing practicality and multiple power options. Below are its core parameters and configuration:
Basic and Chassis Parameters: Overall dimensions are 7420×2460×3180mm, gross vehicle weight is 16200kg, curb weight is 8450kg, and rated payload is 7620kg or 7555kg. Built on the EQ1165LJ9CDE chassis, it has a wheelbase of 3950mm, comes with various tire models, and is equipped with an ABS system, offering strong driving stability and adaptability. Its maximum speed reaches 105km/h.
Power Configuration: Nine types of China VI diesel engines from multiple manufacturers, including Dongfeng Cummins and Guangxi Yuchai, are available, such as the D4.0NS6B195 and YCS04200-68 models. Engine displacement ranges from 2.97L to 6.2L, and power ranges from 121kW to 169kW, meeting the power requirements of various operating scenarios.
Core Operating Configuration: Equipped with an oval-shaped asphalt tank with a total capacity of 8.8 cubic meters and an effective volume of 8.38 cubic meters. A 50mm thick insulation layer is installed between the inner and outer tank liner to effectively preserve liquid asphalt. Side protection is made of Q235 material and welded in place. The rear protective structure is replaced by a special device with its lower edge 480mm above the ground, ensuring operational safety.
