Dongfeng 15-ton tipper truck for export features a 190–260 hp diesel engine, 8–10 speed manual transmission, and 15-ton payload. Its hydraulic tipping system and reinforced steel body ensure durability for mining and construction. Customizable for RHD and harsh environments, with global after-sales support.
| GVW | Driving Type 4x2 | |
Model | Luke | |
Cab | Tianjin KR a row and a half deluxe cab(with sleeping berth),hydraulic mechanical flip, channel type instrument panel, air conditioner, allowable 3 passengers | |
Engine(Hp) | 190 | |
Power(Kw) | 140 | |
Wheelbase | 3950 | |
Front/Rear Suspension | 1430/1700 | |
Steering | Power steering | |
Approach/departure angle | 25/20 | |
Wheels & tire | 10.00R20 | |
Tire number | 6+1 | |
Tank Dimensions(mm) | 4500×2300×800 | |
Cubage (m3) | 8 | |
Steel thickness | Side 4 ,Bottom 4 | |
RHD or LHD | optional | |
Overall Dimensions(mm) | 7100×2500×3200 | |
Curb weight (Kg) | 6800 | |
Engine | Model | B190 33 |
Horsepower | 190 | |
Maximum output Kw | 140 | |
Maximum torque N.m | 640 | |
Type | 6 cylinders, in-line,4-stroke,water-cooled,turbo inter-cooling, diesel engine | |
Displacement | 5.9L | |
Cummins brand, Euro 3 | ||
Driving passenger | 3 | |
Transmission | FAST 8 speed forward and one reverse, manual | |
Front Axle | 5T | |
Rear Axle | 10T | |
Brake System | air brake exhaust brake | |
Color and LOGO | customized | |
Electric system | 24V | |
Standard configuration | The dump is unloaded from behind, hydraulic cover is optional. The side protection using cold-formed steel /Q235-A, bolt connection. The back protection using cold-formed steel /Q235-A, welding connection. Side 4mm, bottom 4mm. | |
Delivery date | Within 30 days after receipt advance | |
Packing | Nude Pack .The packing of the commodity shall be in accordance with the export standard packing of the manufacturer, be suitable for long distance transportation of ocean and inland. The Seller shall be take measures against moisture, shocks and rust according to the special needs of the commodity. | |
