Item | Specification | Item | Specification |
Brand | Qiyuan | Overall Dimensions (mm) | 5,995 × 2,280 × 3,430 |
Product Name | Fire Communication & Command Vehicle | Model | QY5067TXFTZ2500 |
Gross Vehicle Weight (kg) | 5,720 | Curb Weight (kg) | 5,495 |
Cab Seating Capacity | 3 | Wheelbase (mm) | 3,700 |
Approach/Departure Angle (°) | 33/19 | Front/Rear Overhang (mm) | 1,018/1,277 |
Axle Load (kg) | 2,500/3,220 | Maximum Speed (km/h) | 130 |
Integral side protection structure. Rear protection material: Q235A, cross-section size (W×H): 60 × 120 mm, bolted connection to the vehicle, rear protection ground clearance: 390 mm. ABS system models/manufacturers: CM0953YK / Guangzhou Ruili Kemi Automotive Electronics Co., Ltd., CM9003YK / Guangzhou Ruili Kemi Automotive Electronics Co., Ltd. Side seats are not occupied during driving. Site lighting is installed on the vehicle’s side/rear, for operation use only. Main special equipment includes communication devices. | |||
Chassis Technical Specifications | |||
Item | Specification | Item | Specification |
Chassis Model | EQ2068FYY6J | Chassis Name | Off-Road Vehicle Chassis |
Brand | Dongfeng | Manufacturer | Dongfeng Motor Group Co., Ltd. |
Number of Axles | 2 | Number of Tires | 4 |
Tire Specification | 295/65R20LT (10PR) | Emission Standard | GB17691-2018 China National VI |
Leaf Spring Configuration | -/- | Front Track (mm) | 1,831 |
Fuel Type | Diesel | Rear Track (mm) | 1,831 |
Engine Model | Engine Manufacturer | Displacement (ml) | Power (kW) |
D6.7NS6B120 | Dongfeng Cummins Engine Co., Ltd. | 6,700 | 85 |
