Foton's four-wheel-drive off-road crowd evacuation ambulance is used in densely populated areas to promptly transport trapped individuals, thereby more efficiently protecting the lives of more people.This product is very popular in countries such as Saudi Arabia, the UAE, Qatar, Kuwait, Oman, Bahrain, and Yemen.
| Four-Wheel Drive Off-Road Foton Crowd Evacuation Vehicle Overall Vehicle Technical Parameters | |||
| Product Trademark | Casal | Announcement Batch | 378（expand） |
| Product Name | Ambulance | Product Model | LOOK5045XJH |
| Total Mass（KG） | 4495 | External Dimensions(mm) | 5952×2430×2930 |
| Curb Weight（KG） | 3300 | Rated Passenger Capacity（/） | 7 |
| Approach Angle/Departure Angle(°) | 20/19 | Front/Rear Suspension(mm) | 993/1409 |
| Axle Load | 1685/2810 | Maximum Speed | 140 |
| It uses an F2.8NS6B177L engine with a maximum net power of 130kW. ABS model: YF8, manufactured by Wuhan Yuanfeng Auto Electronic Control System Co., Ltd. It is equipped with a warning light and alarm system, automatic loading stretcher, medical equipment cabinet, sliding IV stand, oxygen cylinder, medical cabinet, ultraviolet disinfection lamp, medical cabin lighting, fire extinguisher, magnetic flashing warning lights, side flashing lights, rear flashing lights, medical equipment cabinet, negative pressure purification system, and other ambulance-specific equipment. Optional features include front fog lights, front grille and front bumper color, aluminum wheels, wheel covers, axle head covers, and rearview mirrors. Optional features include a direct-powered ETC system; side and lower rear side skirts replace the function of side and rear protection, with a rear protection ground clearance of 480mm. | |||
| Chassis TechnicalPTarameters | |||
| Chassis Model | BJ1048VATD7-E1 | Chassis Name | Cargo Truck Chassis |
| Trademark Name | Foton | Manufacturing Enterprises | Foton |
| Number of Axes | 2 | Number of Tires | 6 |
| Wheelbase(mm) | 3550 | Tire Specifications | 215/75R16LT 8PR |
| Number of Leaf Springs | -/2 | Front Wheel Track(mm) | 1740 |
| Fuel Types | Diesel Fuel | Rear Wheel Track(mm) | 1594 |
| Emission Standards | GB17691-2018 China Ⅵ | ||
| Engine Model | Engine manufacturers | Displacement(ml) | power(Kw) |
| F2.8NS6B177L | Foton | 2780 | 130 |
